Counterflow Cooling Tower
Features and Strengths of Counterflow Cooling Tower

  • The square design of the exterior can be installed side-by-side in an orderly manner.

  • The fan stack and wide filler area ensure low internal pressure and guarantee low power consumption.

  • The casing can be made with FRP, zinc plate, and SUS depending on the customer’s preferences.

  • Reducing water drift to within 0.02% can lead to a reduction of coolant.

  • The outdoor enclosed motor is used as it is often used in places with high humidity.

  • The material of coolant distribution pipes is PVC and the low spray pressure ensures good distribution of coolant.

  • Reducing water drift to within 0.02% can lead to a reduction of coolant.

  • The air inlet prevents coolant from splashing outside and keeps foreign substances from entering the cold water basin.

Specifications
Heat load(kcal/hr) 312,000 Width(mm) 1,890
Water flow rate(㎥/h) 62.4 Length(mm) 1,890
Height(mm) 2890
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 1,300 x 1 Power(HP-P) 5
Fan Speed(rpm) 580 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
100Ax1 100Ax1 50Ax1 50Ax1 25Ax1 25Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 700
Drift Loss (%) Less than 0.02 Operating Weight (kg) 1,400

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement

Heat load(kcal/hr) 390,000 Width(mm) 2,050
Water flow rate(㎥/h) 78 Length(mm) 2,050
Height(mm) 2890
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 1,300 x 1 Power(HP-P) 5
Fan Speed(rpm) 580 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
125Ax1 125Ax1 50Ax1 50Ax1 25Ax1 25Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 820
Drift Loss (%) Less than 0.02 Operating Weight (kg) 1,670

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 487,000 Width(mm) 2,200
Water flow rate(㎥/h) 97.5 Length(mm) 2,200
Height(mm) 2890
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 1,500x1 Power(HP-P) 5
Fan Speed(rpm) 489 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
125Ax1 125Ax1 50Ax1 50Ax1 25Ax1 25Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 960
Drift Loss (%) Less than 0.02 Operating Weight (kg) 1,950

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 585,000 Width(mm) 2,550
Water flow rate(㎥/h) 117 Length(mm) 2,350
Height(mm) 3,185
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 1,700x1 Power(HP-P) 5
Fan Speed(rpm) 486 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
150Ax1 150Ax1 50Ax1 50Ax1 25Ax1 25Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,120
Drift Loss (%) Less than 0.02 Operating Weight (kg) 2,370

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 682,500 Width(mm) 2,550
Water flow rate(㎥/h) 136.5 Length(mm) 2,350
Height(mm) 3,185
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 1,700x1 Power(HP-P) 5
Fan Speed(rpm) 534 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
150Ax1 150Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,170
Drift Loss (%) Less than 0.02 Operating Weight (kg) 2,480

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 780,000 Width(mm) 3,350
Water flow rate(㎥/h) 156 Length(mm) 2,350
Height(mm) 3,335
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x1 Power(HP-P) 7.5
Fan Speed(rpm) 437 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
150Ax1 150Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,350
Drift Loss (%) Less than 0.02 Operating Weight (kg) 2,870

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 877,500 Width(mm) 3,350
Water flow rate(㎥/h) 175.5 Length(mm) 2,350
Height(mm) 3,335
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x1 Power(HP-P) 7.5
Fan Speed(rpm) 481 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax1 200Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,500
Drift Loss (%) Less than 0.02 Operating Weight (kg) 3,000

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 975,000 Width(mm) 4,150
Water flow rate(㎥/h) 195 Length(mm) 2,350
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x1 Power(HP-P) 10
Fan Speed(rpm) 481 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax1 200Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,720
Drift Loss (%) Less than 0.02 Operating Weight (kg) 3,760

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 1,170,000 Width(mm) 4,150
Water flow rate(㎥/h) 234 Length(mm) 2,350
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x1 Power(HP-P) 15x1
Fan Speed(rpm) 477 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax1 200Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 1,800
Drift Loss (%) Less than 0.02 Operating Weight (kg) 3,600

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 1,365,000 Width(mm) 4,700
Water flow rate(㎥/h) 273 Length(mm) 2,550
Height(mm) 3,535
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x1 Power(HP-P) 15x1
Fan Speed(rpm) 395 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax1 200Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 2,400
Drift Loss (%) Less than 0.02 Operating Weight (kg) 4,800

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 1,560,000 Width(mm) 4,700
Water flow rate(㎥/h) 312 Length(mm) 2,550
Height(mm) 3,535
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,400x1 Power(HP-P) 20x1
Fan Speed(rpm) 395 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
250Ax1 250Ax1 65Ax1 65Ax1 40Ax1 40Ax1
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 2,500
Drift Loss (%) Less than 0.02 Operating Weight (kg) 5,000

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 1,950,000 Width(mm) 4,150
Water flow rate(㎥/h) 390 Length(mm) 4,700
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x2 Power(HP-P) 10x2
Fan Speed(rpm) 481 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax2 200Ax2 65Ax2 65Ax2 40Ax2 40Ax2
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 3,400
Drift Loss (%) Less than 0.02 Operating Weight (kg) 6,800

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 2,340,000 Width(mm) 4,150
Water flow rate(㎥/h) 468 Length(mm) 4,700
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x2 Power(HP-P) 15x2
Fan Speed(rpm) 481 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax2 200Ax2 65Ax2 65Ax2 40Ax2 40Ax2
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 3,600
Drift Loss (%) Less than 0.02 Operating Weight (kg) 7,200

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 2,730,000 Width(mm) 4,700
Water flow rate(㎥/h) 546 Length(mm) 5,100
Height(mm) 3535
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,400x2 Power(HP-P) 15x2
Fan Speed(rpm) 395 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax2 200Ax2 65Ax2 65Ax2 40Ax2 40Ax2
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 4,800
Drift Loss (%) Less than 0.02 Operating Weight (kg) 9,600

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 3,120,000 Width(mm) 4,700
Water flow rate(㎥/h) 624 Length(mm) 5,100
Height(mm) 3535
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,400x2 Power(HP-P) 20x2
Fan Speed(rpm) 395 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
250Ax2 250Ax2 65Ax2 65Ax2 40Ax2 40Ax2
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 5,000
Drift Loss (%) Less than 0.02 Operating Weight (kg) 10,000

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 3,510,000 Width(mm) 4,150
Water flow rate(㎥/h) 702 Length(mm) 7,050
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,000x3 Power(HP-P) 15x3
Fan Speed(rpm) 477 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax3 200Ax3 65Ax3 65Ax3 40Ax3 40Ax3
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 5,400
Drift Loss (%) Less than 0.02 Operating Weight (kg) 10,800

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.

Heat load(kcal/hr) 3,900,000 Width(mm) 4,700
Water flow rate(㎥/h) 780 Length(mm) 7,650
Height(mm) 3,385
Materials of Key Components
Casing Basin support Filler&Eliminator Nozzle pipe Spray nozzle Cold water basin Louver Fan assembly Fan stack
F.R.P / P.V.C / Steel SS400 + H.D.G
(zinc plating)		 P.V.C & P.P P.V.C P.P F.R.P P.V.C Blade : F.R.P, Hub : Al-alloy & STS F.R.P
Fan assembly
Fan Motor
Diameter(mm) 2,400x3 Power(HP-P) 15x3
Fan Speed(rpm) 477 Power source 220 / 380 / 440 V 60Hz (TEAO)
Drive System Single Reduction V-Belt Drive Driving type V - BELT Drive
Piping
Water Inlet Pipe Water Outlet Pipe Drain Over Flow Make-up (Auto) Make-up (Manual)
200Ax3 200Ax3 65Ax3 65Ax3 40Ax3 40Ax3
Loss Rate Weight
Evaporation Loss (%) 0.87 Self-weight (kg) 7,200
Drift Loss (%) Less than 0.02 Operating Weight (kg) 14,400

※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.

※The above specifications are subject to change due to product improvement.
