| Capacity(kcal/HRX10³) |
1,950 |
Water((M³XHR)) |
390 |
Dimensions
| Width(mm) |
4,640 |
Length(mm) |
4,640 |
| H(mm) |
4,800 |
h(mm) |
1,300 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 2500 |
15 |
| Weight |
| NET(kg) |
5,300 |
OPER-(kg) |
10,300 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
2,340 |
Water((M³XHR)) |
468 |
Dimensions
| Width(mm) |
4,640 |
Length(mm) |
4,640 |
| H(mm) |
4,800 |
h(mm) |
1,300 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 3150 |
20 |
| Weight |
| NET(kg) |
5,500 |
OPER-(kg) |
10,750 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
2,730 |
Water((M³XHR)) |
546 |
Dimensions
| Width(mm) |
5,340 |
Length(mm) |
5,340 |
| H(mm) |
5,150 |
h(mm) |
1,300 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 3150 |
20 |
| Weight |
| NET(kg) |
6,750 |
OPER-(kg) |
13,300 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
3,120 |
Water((M³XHR)) |
624 |
Dimensions
| Width(mm) |
5,690 |
Length(mm) |
5,690 |
| H(mm) |
5,250 |
h(mm) |
1,300 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 3150 |
25 |
| Weight |
| NET(kg) |
7,450 |
OPER-(kg) |
14,750 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
3,510 |
Water((M³XHR)) |
702 |
Dimensions
| Width(mm) |
5,740 |
Length(mm) |
5,740 |
| H(mm) |
5,200 |
h(mm) |
1,550 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 3550 |
30 |
| Weight |
| NET(kg) |
8,250 |
OPER-(kg) |
15,950 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
3,900 |
Water((M³XHR)) |
780 |
Dimensions
| Width(mm) |
6,090 |
Length(mm) |
6,090 |
| H(mm) |
5,300 |
h(mm) |
1,550 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4000 |
30 |
| Weight |
| NET(kg) |
9,050 |
OPER-(kg) |
17,500 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
4,290 |
Water((M³XHR)) |
856 |
Dimensions
| Width(mm) |
6,265 |
Length(mm) |
6,265 |
| H(mm) |
5,350 |
h(mm) |
1,550 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4000 |
40 |
| Weight |
| NET(kg) |
9,550 |
OPER-(kg) |
18,650 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
4,680 |
Water((M³XHR)) |
936 |
Dimensions
| Width(mm) |
6,615 |
Length(mm) |
6,615 |
| H(mm) |
5,450 |
h(mm) |
1,550 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4000 |
40 |
| Weight |
| NET(kg) |
10,300 |
OPER-(kg) |
20,300 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
5,070 |
Water((M³XHR)) |
1,014 |
Dimensions
| Width(mm) |
6,790 |
Length(mm) |
6,790 |
| H(mm) |
5,550 |
h(mm) |
1,800 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4000 |
40 |
| Weight |
| NET(kg) |
10,850 |
OPER-(kg) |
21,350 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
5,460 |
Water((M³XHR)) |
1,092 |
Dimensions
| Width(mm) |
7,140 |
Length(mm) |
7,140 |
| H(mm) |
5,700 |
h(mm) |
1,800 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4500 |
50 |
| Weight |
| NET(kg) |
11,800 |
OPER-(kg) |
24,450 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
5,850 |
Water((M³XHR)) |
1,170 |
Dimensions
| Width(mm) |
7,315 |
Length(mm) |
7,315 |
| H(mm) |
5,750 |
h(mm) |
1,800 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4500 |
60 |
| Weight |
| NET(kg) |
12,250 |
OPER-(kg) |
25,400 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
6,240 |
Water((M³XHR)) |
1,248 |
Dimensions
| Width(mm) |
7,490 |
Length(mm) |
7,490 |
| H(mm) |
5,750 |
h(mm) |
1,800 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4500 |
60 |
| Weight |
| NET(kg) |
12,700 |
OPER-(kg) |
26,500 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
7,020 |
Water((M³XHR)) |
1,404 |
Dimensions
| Width(mm) |
7,840 |
Length(mm) |
7,840 |
| H(mm) |
5,750 |
h(mm) |
1,800 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 4500 |
60 |
| Weight |
| NET(kg) |
14,150 |
OPER-(kg) |
29,400 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
7,800 |
Water((M³XHR)) |
1,560 |
Dimensions
| Width(mm) |
8,365 |
Length(mm) |
8,365 |
| H(mm) |
6,150 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 5600 |
60 |
| Weight |
| NET(kg) |
15,650 |
OPER-(kg) |
32,500 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
8,580 |
Water((M³XHR)) |
1,716 |
Dimensions
| Width(mm) |
8,715 |
Length(mm) |
8,715 |
| H(mm) |
6,150 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 5600 |
75 |
| Weight |
| NET(kg) |
16,500 |
OPER-(kg) |
34,750 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
9,360 |
Water((M³XHR)) |
1,872 |
Dimensions
| Width(mm) |
8,940 |
Length(mm) |
8,940 |
| H(mm) |
6,300 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 5600 |
100 |
| Weight |
| NET(kg) |
19,100 |
OPER-(kg) |
38,850 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
9,750 |
Water((M³XHR)) |
1,950 |
Dimensions
| Width(mm) |
9,290 |
Length(mm) |
9,290 |
| H(mm) |
6,500 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 5600 |
100 |
| Weight |
| NET(kg) |
20,100 |
OPER-(kg) |
40,950 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
10,140 |
Water((M³XHR)) |
2,028 |
Dimensions
| Width(mm) |
9,640 |
Length(mm) |
9,640 |
| H(mm) |
6,550 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 5600 |
100 |
| Weight |
| NET(kg) |
21,150 |
OPER-(kg) |
43,400 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
10,920 |
Water((M³XHR)) |
2,184 |
Dimensions
| Width(mm) |
9,990 |
Length(mm) |
9,990 |
| H(mm) |
6,550 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 6300 |
100 |
| Weight |
| NET(kg) |
22,700 |
OPER-(kg) |
48,250 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
| Capacity(kcal/HRX10³) |
11,700 |
Water((M³XHR)) |
2,340 |
Dimensions
| Width(mm) |
10,340 |
Length(mm) |
10,340 |
| H(mm) |
6,800 |
h(mm) |
2,050 |
Fan assembly
| FAN DIA(ømm) |
MOTOR(Hp) |
| 6300 |
100 |
| Weight |
| NET(kg) |
23,950 |
OPER-(kg) |
50,850 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃.
※The above specifications are subject to change due to product improvement.
