| Cooling capacity(kcal/hr) |
390,000 |
Width(mm) |
3830 |
| Water flow rate(ipm) |
1300 |
Length(mm) |
1580 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2530 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
2885 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 3-8 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 1300 |
657 |
4/580 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 80 x 2 |
125 x 1 |
50 x 1 |
50 x 1 |
25 x 1 |
25 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1350 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
3100 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
487,500 |
Width(mm) |
3830 |
| Water flow rate(ipm) |
1625 |
Length(mm) |
1580 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2530 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
2885 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 4-8 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 1300 |
822 |
4/656 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 80 x 2 |
125 x 1 |
50 x 1 |
50 x 1 |
25 x 1 |
25 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1360 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
3150 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
585,000 |
Width(mm) |
4050 |
| Water flow rate(ipm) |
1950 |
Length(mm) |
1830 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2530 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
2980 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 5-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 1500 |
986 |
4/492 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 100 x 2 |
150 x 1 |
50 x 1 |
50 x 1 |
32 x 1 |
32 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1550 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
3580 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
682,500 |
Width(mm) |
4050 |
| Water flow rate(ipm) |
2275 |
Length(mm) |
1830 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2530 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
2980 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 7.5-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 1500 |
1150 |
4/599 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 100 x 2 |
150 x 1 |
50 x 1 |
50 x 1 |
32 x 1 |
32 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1570 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
3620 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
780,000 |
Width(mm) |
4270 |
| Water flow rate(ipm) |
2600 |
Length(mm) |
2080 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2685 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3000 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 7.5-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 1700 |
1314 |
4/535 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 2 |
150 x 1 |
65 x 1 |
50 x 1 |
32 x 1 |
32 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1690 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
3950 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
877,500 |
Width(mm) |
4520 |
| Water flow rate(ipm) |
2925 |
Length(mm) |
2350 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2685 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3000 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 7.5-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2000 |
1479 |
4/438 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 2 |
200 x 1 |
65 x 1 |
50 x 1 |
32 x 1 |
32 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1820 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
4470 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
975,000 |
Width(mm) |
4520 |
| Water flow rate(ipm) |
3250 |
Length(mm) |
2350 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2685 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3000 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 10-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2000 |
1640 |
6/480 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 2 |
200 x 1 |
65 x 1 |
50 x 1 |
32 x 1 |
32 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
1850 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
4520 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
1,170,000 |
Width(mm) |
4700 |
| Water flow rate(ipm) |
3900 |
Length(mm) |
2600 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2825 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3525 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 10-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2200 |
1970 |
6/430 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 2 |
200 x 1 |
80 x 1 |
80 x 1 |
40 x 1 |
40 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
2090 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
4670 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
1,365,000 |
Width(mm) |
4700 |
| Water flow rate(ipm) |
4550 |
Length(mm) |
2600 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2825 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3525 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 15-4 |
200 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2200 |
2300 |
6/430 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 2 |
200 x 1 |
80 x 1 |
80 x 1 |
40 x 1 |
40 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
2240 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
5250 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
1,560,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
5200 |
Length(mm) |
2800 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2985 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3950 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 15-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 |
2630 |
6/400 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 2 |
250 x 1 |
80 x 1 |
80 x 1 |
50 x 1 |
50 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
2790 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
7240 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
1,755,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
5850 |
Length(mm) |
2800 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
3305 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3905 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 20-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 |
3150 |
6/435 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 2 |
250 x 1 |
80 x 1 |
80 x 1 |
50 x 1 |
50 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
2940 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
7400 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
1,950,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
6500 |
Length(mm) |
3000 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
3305 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3905 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 20-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 |
3290 |
6/435 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 2 |
250 x 1 |
80 x 1 |
80 x 1 |
50 x 1 |
50 x 1 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
3100 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
7700 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
2,340,000 |
Width(mm) |
4700 |
| Water flow rate(ipm) |
7800 |
Length(mm) |
2600 x 2 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2825 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3525 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 10-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2200 x 2 |
1970 x 2 |
6x2/400 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 4 |
200 x 2 |
80 x 2 |
80 x 2 |
40 x 2 |
40 x 2 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
4180 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
9340 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
2,730,000 |
Width(mm) |
4700 |
| Water flow rate(ipm) |
9100 |
Length(mm) |
2600 x 2 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2825 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3525 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 15-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2200 x 2 |
2300 x 2 |
6x2/430 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 125 x 4 |
200 x 2 |
80 x 2 |
80 x 2 |
40 x 2 |
40 x 2 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
4480 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
10500 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
3,120,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
10400 |
Length(mm) |
2800 x 2 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
2985 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3950 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 15-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 x 2 |
2630 x 2 |
6x2/430 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 4 |
250 x 2 |
80 x 2 |
80 x 2 |
50 x 2 |
50 x 2 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
5580 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
14480 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
3,510,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
11700 |
Length(mm) |
2800 x 2 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
3305 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3905 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 20-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 x 2 |
3150 x 2 |
6x2/435 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 4 |
250 x 2 |
80 x 2 |
80 x 2 |
50 x 2 |
50 x 2 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
5880 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
14480 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
| Cooling capacity(kcal/hr) |
3,900,000 |
Width(mm) |
5720 |
| Water flow rate(ipm) |
13000 |
Length(mm) |
3000 x 2 |
| Water in-let temp(℃) |
37 |
Deck Height(mm) |
3305 |
| Water out-let temp(℃) |
32 |
Overall Height(mm) |
3905 |
| Wet bulb temp(℃) |
27 |
|
|
Materials of Key Components
| Fan stack |
Casing |
Hot water basin |
Cold water basin |
Filler |
Frame |
Fan blade |
Fan hub |
| F.R.P |
P.V.C |
F.R.P |
F.R.P |
P.V.C & P.P |
SS400 + Z.H.D
(zinc plating) |
AL - Alloy or F.R.P |
AL - Alloy |
Motor
| HP / P |
Power source |
Driving type |
| 20-4 |
3H 220 / 380 / 440 V 60Hz(TEAO) |
V-BELT |
Fan
| Diameter(mm) |
Air volume(CMM) |
No. of blade |
| 2400 x 2 |
3290 x 2 |
6x2/435 |
Piping
| Inlet(A) |
Outlet(A) |
Overflow(A) |
Drain(A) |
Auto makeup(A) |
Man makeup(A) |
| 150 x 4 |
250 x 2 |
80 x 2 |
80 x 2 |
50 x 2 |
50 x 2 |
| Loss Rate |
Weight |
| Evaporation Loss (%) |
0.83 |
Self-weight (kg)(kg) |
6200 |
| Drift Loss (%) |
Less than 0.02 |
Operating Weight (kg) |
15400 |
※Standard capacity: 1 R/T is 3,900 kcal/hr when the inlet air wet-bulb temperature is 27℃, the inlet water temperature is 37℃, and the outlet water temperature is 32℃
※The above specifications are subject to change due to product improvement.
